Page #116 background image
Installing a UFM on page 117
Removing a UFM on page 119
Replacing a UFM4 with a UFM3 on page 120
UFM6 Installation Rules on page 121
UFM Specifications
Table 42: UFM Specifications
SpecificationItem
Physical Dimensions
28.9 mm1.14 inWidth
350.0 mm13.75 inHeight
300.0 mm11.75 inDepth
Power Consumption (40°C ambient)
NOTE: Before using for planning or implementation
purposes, contact Juniper Networks Support to
confirm the power consumption values.
Typical: 32 W
Maximum: 35 W
Universal Forwarding Module (BT8A78UFM3)
Typical: 140 W
Maximum: 154 W
Universal Forwarding Module with Integrated 100G
Coherent MSA XCVR (BT8A78UFM4)
Typical:
With 10 x QSFP+ transceivers installed: 305 W
With 4 x QSFP28 transceivers installed: 295 W
Universal Forwarding Module with Integrated 400G
Coherent MSA XCVR (BT8A78UFM6-I02)
See “Service Module LEDs” on page 151.LEDs
UFM Latches
The top and bottom latches of a UFM must be fully closed for proper module operation.
“UFM Latches” on page 116 and “UFM Latches” on page 116 show the open and closed
positions of the top latch on each type of UFM.
Copyright © 2019, Juniper Networks, Inc.116
