Table 33: Miscellaneous Kits and Accessories (continued)
DescriptionPECName
Additional bracket for use when
mounting the BTI7801 chassis into a
4-post 19-inch or ETSI 600-mm cabinet.
BT8A78SSB3BTI7801 Chassis Support Bracket Kit
Tools for Installation
Tools to have on-hand when you are ready to install the BTI7800 Series chassis:
•
Number 1 Phillips screwdriver
•
Number 2 Phillips screwdriver
•
10 mm socket or wrench
•
T15 Torx
®
screwdriver (for fastening mounting brackets onto a BTI7814 chassis)
•
Grounded antistatic mat to place modules
•
ESD grounding strap to prevent electrostatic discharge damage
•
Wire stripping and crimping tool
•
Multimeter
•
Tape measure, to verify adequate spacing around the rack, and between chassis in a
multi-chassis rack configuration
Installing the BTI7802 Chassis Rear Exhaust Adapter
Use this procedure to install the Rear Exhaust Adapter onto a BTI7802 chassis to
accommodate front-to-rear airflow when the chassis is mounted onto a 23-inch rack.
Prerequisites:
Copyright © 2019, Juniper Networks, Inc.78
BTI7800 Series Hardware Overview and Installation Guide
