CHAPTER 6
BTI7800 Series Transceiver Specifications
BTI7800 Transceivers on page 153
BTI7800 SFP+ Transceiver Optical Specifications on page 155
BTI7800 QSFP+ Transceiver Optical Specifications on page 162
BTI7800 QSFP28 Transceiver Optical Specifications on page 168
BTI7800 100-Gbps Transceiver Optical Specifications on page 171
BTI7800 400-Gbps Transceiver Optical Specifications on page 176
Installation Rules for the 100G Coherent CFP on page 177
Cleaning Transceivers on page 177
BTI7800 Transceivers
Table 55: BTI7800 Series Transceivers
IntroducedCompatibilityPECBit RateFiber TypeType
Release 1.112x SFP+ BIC in
UFM3 and UFM4
BP3AD6SS10.3 and 10.5
Gbps
MultimodeSFP+ 850nm 200m
Dual-Rate 10.3 and
10.5Gbps
Release 1.112x SFP+ BIC in
UFM3 and UFM4
BP3AM6MS9.9 to 11.1 GbpsSingle-modeSFP+ 1310nm 10km
Multi-Rate 9.9 to 11.1Gbps
Release 1.112x SFP+ BIC in
UFM3 and UFM4
BP3AM6DL-xx9.9 to 11.1 GbpsSingle-modeSFP+ DWDM Fixed 80km
Multi-Rate 9.9 to 11.1Gbps
Release 1.112x SFP+ BIC in
UFM3 and UFM4
BP3AM6TL9.9 to 11.1 GbpsSingle-modeSFP+ DWDM Tunable
80km Multi-Rate 9.9 to
11.1Gbps
Release 4.1UFM6QSFPP-4X10GE-LR
(740-054050)
4x10 GbpsParallel
single-mode
QSFP+ 4x10GBASE LR
Release 4.2UFM6QSFPP-4X10GD-LR
(740-058730)
4x10 GbpsParallel
single-mode
QSFP+ 4x10G
Ethernet/OTN LR
Release 4.3UFM6QSFPP-4X10GE-SR
(740-054053)
4x10 GbpsParallel
multimode
QSFP+ 4x10GBASE SR
153Copyright © 2019, Juniper Networks, Inc.
