Table 48: AMP1 (BT8A78AMP1) Specifications (continued)
SpecificationItem
Monitor
DCM
Line
C1
Connectors/Ports
AMP1 Latches
The top and bottom latches of the AMP1 have a spring-loaded locking mechanism. Both
latches must be fully closed and locked for proper module operation.
Installing an AMP1 Module
Use this procedure to install a 96-Channel Amplifier (AMP1).
Prerequisites:
•
If you have pre-provisioned the module, ensure the module is administratively enabled.
If the module is not administratively enabled, the module will not be acknowledged
by the CMM. For information on how to enable the module, see the BTI7800 Software
Configuration Guide.
•
If you have not pre-provisioned the module and you are relying on auto-provisioning,
then the system will automatically provision and enable the module for you. You do
not need to manually enable the module in this case.
Tools Required
•
Number 2 Phillips screwdriver
NOTE: Be familiar with the site, safety, and installation guidelines described
in “Module Installation and Removal Guidelines” on page 108.
133Copyright © 2019, Juniper Networks, Inc.
Chapter 5: BTI7800 Series Modules
