CHAPTER 5
BTI7800 Series Modules
List Of Modules on page 107
Module Installation and Removal Guidelines on page 108
Chassis Management Module (CMM) on page 110
Universal Forwarding Module (UFM) on page 115
BTI Interface Card (BIC) on page 122
96-Channel Amplifier (AMP1) on page 130
Wavelength Protection Switch (WPS4) on page 135
96-Channel Fixed Mux/Demux (FMD96) on page 142
Service Module LEDs on page 151
Port LEDs on page 152
List Of Modules
The following table lists the management and traffic modules for the BTI7800. Traffic
modules refer to all modules that carry user traffic, and include service modules, BTI
Interface Cards, and passive rack-mounted modules.
Table 38: BTI7800 Series Management and Traffic Modules
IntroducedPECDescriptionModule
Management modules
Release 1.1BT8A78CMM1Provides management and control of
the system.
Chassis Management Module 1 (CMM1)
Service modules
Release 1.1BT8A78UFM3Supports two BICs.Universal Forwarding Module (UFM3)
Release 1.1BT8A78UFM4Contains one 100G Coherent MSA
XCVR and supports one BTI Interface
Card (BIC).
Universal Forwarding Module with Integrated
100G Coherent MSA XCVR (UFM4)
Release 4.1BT8A78UFM6-I02Contains a total of ten client ports and
one 400G Coherent MSA XCVR.
1
Universal Forwarding Module with Integrated
400G Coherent MSA XCVR (UFM6)
107Copyright © 2019, Juniper Networks, Inc.
