BTI7814 CAP1 Specifications
Table 28: 14-Slot Chassis Alarm Panel (BT8A78CAP1) Specifications
SpecificationItem
Physical Dimensions
76.2 mm3.00 inWidth
31.8 mm1.25 inHeight
114.3 mm4.50 inDepth
0.22 kg0.5 lbsWeight
Typical: 2 W
Maximum: 2.4 W
Power Consumption (40°C ambient)
NOTE: Before using for planning or implementation
purposes, contact Juniper Networks Support to
confirm the power consumption values.
Critical: RedLEDs
Minor: Amber
Major: Red
OOS (Out-of-service): Red
Power: Green
BTI7802 CAP
The BTI7802 chassis is shipped with the Chassis Alarm Panel (CAP) module installed
(BT8A78CAP2). The CAP is located on the bottom right, at the front of the chassis, and
provides the following functions:
•
Alarm Cutoff (ACO)/Lamp test button
•
Alarm LEDs
•
Telco (Office) Alarm Connector (for pin assignments and input voltages, see “CAP
Telco Alarm Connector Pin Assignments” on page 218)
