Juniper BTI7800 Series - Table 63: QSFP+ 4 X10 G EthernetOtn LR: QSFPP-4 X10 GD-LR (740-058730)

Table 63: QSFP+ 4x10G Ethernet/OTN LR: QSFPP-4X10GD-LR (740-058730) (continued)
UnitsMaximumTypicalMinimumParameter
dBm0.5–-8.210GBASEAverage launch power per
lane
dBm-1–-6OC192/STM64
dBm-1–-6OTU2
dBm-1–-6OTU2e
dBm-1–-8.48GFC
dBm0.5–-8.210GFC
dB––3.510GBASEExtinction ratio
dB––6OC192/STM64
dB––6OTU2
dB––6OTU2e
dB––3.58GFC
dB––3.510GFC
dB12––Optical return loss tolerance
Receiver
dBm0.5–-14.4Average receive power per lane
dBm-10.3––Stressed receiver sensitivity (OMA) per lane
dB-12––Reflectance
Other
SMFFiber type
m10000–2Reach
MTP/APCConnector/Latch type
Maximum: 3.5 WPower consumption
IEEE 802.3, GR-253-Core, FC-PI-4Compliance
