Table 13: BTI7802 Chassis Specifications (continued)
SpecificationShell
15 lb
6.80 kg
Weight (unpopulated chassis)
1000 WTotal chassis power (fully populated)
GR-1089
GR-3160
NEBS
BTI7801 Chassis
The BTI7801 is a 1-slot chassis designed to extend BTI7800 reach to smaller sites that
require point-to-point connectivity. The BTI7801 contains one service slot and one
management slot, and can be mounted onto 19-inch, 23-inch, and ETSI 600-mm
(600-mm (W) x 800-mm (D) cabinets) racks.
The service module and the cooling module are installed at the front of the chassis:
Figure 6: BTI7801 Chassis Front View
The Chassis Management Module, Ethernet and Serial Link module, and redundant Power
Entry Modules are installed at the rear of the chassis:
37Copyright © 2019, Juniper Networks, Inc.
Chapter 2: BTI7800 Series Chassis
