Table 45: 1x CFP BIC (BT8A78CFP1G) Specifications (continued)
SpecificationItem
0.45 kg1.0 lbWeight
Typical: 32W
Maximum: 38W
Power Consumption (40°C ambient)
NOTE: Before using for planning or implementation
purposes, contact Juniper Networks Support to
confirm the power consumption values.
See “BIC LEDs” on page 130.LEDs
100GbE, 103.125 GbpsSupported Protocols
OTN OTU4, 111.809 Gbps
RS FEC per G.975Supported Forward Error Correction Modes (FEC)
Super FEC (proprietary)
CFP pluggable opticsConnectors/Ports
BIC Handles and Latches
Each BIC features a handle at the top and a latch at the bottom. The bottom latch must
be fully closed for proper module operation.
Installing a BIC
Use this procedure to install a BTI Interface Card (BIC) into a UFM.
Prerequisites:
•
If you have pre-provisioned the module, ensure the module is administratively enabled.
If the module is not administratively enabled, the module will not be acknowledged
by the CMM. For information on how to enable the module, see the BTI7800 Software
Configuration Guide.
•
If you have not pre-provisioned the module and you are relying on auto-provisioning,
then the system will automatically provision and enable the module for you. You do
not need to manually enable the module in this case.
This procedure is the same for all BIC types.
125Copyright © 2019, Juniper Networks, Inc.
Chapter 5: BTI7800 Series Modules
