Juniper BTI7800 Series - AMP1 Specifications; Figure 39: 96-Channel Amplifier Module; Table 48: AMP1 (BT8 A78 AMP1) Specifications

Figure 39: 96-Channel Amplifier Module
•
AMP1 Specifications on page 131
•
AMP1 Latches on page 133
•
Installing an AMP1 Module on page 133
•
Removing an AMP1 Module on page 134
AMP1 Specifications
Table 48: AMP1 (BT8A78AMP1) Specifications
SpecificationItem
Physical Dimensions
30.5 mm1.20 inWidth
350.8 mm13.81 inHeight
325.0 mm12.80 inDepth
1.9 kg4.2 lbWeight
Typical: 68W
Maximum: 75W
Power Consumption (40°C ambient)
NOTE: Before using for planning or implementation
purposes, contact Juniper Networks Support to
confirm the power consumption values.
131Copyright © 2019, Juniper Networks, Inc.
Chapter 5: BTI7800 Series Modules
