Table 74: 100G Coherent CFP: BP3AMCTL (continued)
UnitsMaximumTypicalMinimumParameter
ps15--PMD tolerance
dB3--PDL tolerance
ps/nm22000--22000Dispersion tolerance
dB--27Optical return loss from receiver
Other
Typical: 25W
Maximum: 32W
Power Consumption (40° ambient)
IEEE 802.3, Telcordia GR-253, ITU-T G.709, CFP MSACompliance
Table 75: 100G Coherent MSA XCVR on UFM4
UnitsMaximumTypicalMinimumParameter
Transmitter
THz196.10-191.35Transmitter frequency range
GHz1.8--1.8Laser frequency stability
dBm1--5Output power tuning range
dB--40Transmitter OSNR (in-band)
dB--27Optical return loss tolerance
Receiver
THz196.10-191.35Receiver frequency range
dBm-2--18 (-22dBm in
unamplified
systems)
Input power range
dB--13.7OSNR tolerance
ps30--PMD tolerance
dB3--PDL tolerance
ps/nm50000--50000Dispersion tolerance
