Figure 20: Ethernet and Serial Link Module (BT8A78ESL1)
NOTE: The FAN5 management and craft ports are only operational if the
optional ESL module is installed and connected to the CMM.
BTI7801 ESL Specifications
Table 27: Ethernet and Serial Link (BT8A78ESL1) Specifications
SpecificationItem
Physical Dimensions
44 mm1.7 inWidth
40 mm1.6 inHeight
295 mm11.6 inDepth (excluding handle)
0.45 kg1 lbWeight
Typical: 0.25 W
Maximum: 0.25 W
Power Consumption (40°C ambient)
NOTE: Before using for planning or implementation
purposes, contact Juniper Networks Support to
confirm the power consumption values.
Copyright © 2019, Juniper Networks, Inc.64
BTI7800 Series Hardware Overview and Installation Guide
