Table 52: Service Module LED Behavior (continued)
State DescriptionStateDescriptionName
The operational status of the module is down.OFFThe Active LED reflects the
operational status of the
module.
Active
(GREEN)
The operational status of the module is up.ON
The operational status of the module is up.OFFThe Fail LED reflects the
operational status of the
module.
Fail
(RED)
The operational status of the module is down.ON
The administrative status of the module is up, and the
actual module matches the provisioned module.
The module should not be removed from the chassis in
this state.
OFFThe Hot Swap H/S LED
indicates whether the
module can be removed
from the chassis.
H/S
(BLUE)
The administrative status of the module is down, or the
actual module does not match the provisioned module.
The module can be removed from the chassis in this
state.
ON
This is a transient state that occurs when plugging in a
module, or when changing its administrative status.
The module should not be removed from the chassis in
this state.
BLINKING
Port LEDs
The BTI7800 supports two kinds of port LEDs depending on the module. This is shown
in the following tables.
Table 53: Port LEDs (UFMs and BICs)
DescriptionColorLEDs
The port has failed.RedFail
A fault exists on the port.AmberFault
Table 54: Port LEDs (UFMs and Optical Modules)
DescriptionColorLEDs
The port is operating normally.GreenActive
A fault exists on the port.AmberFault
Copyright © 2019, Juniper Networks, Inc.152
BTI7800 Series Hardware Overview and Installation Guide
