BTI7814 Booster Fan Specifications
Table 24: FAN9 Specifications
SpecificationItem
Physical Dimensions
203.2 mm8 inWidth
88.9 mm3.5 inHeight
152.4 mm6 inDepth
0.9 kg2 lbWeight
Maximum: 125 WPower Consumption (40°C ambient)
NOTE: Before using for planning or implementation
purposes, contact Juniper Networks Support to
confirm the power consumption values.
160 CFMAir Flow
Active: Green
Fail: Red
LEDs
BTI7802 Cooling System
The BTI7802 chassis is shipped with the cooling module installed. The cooling module
contains three fans, and only one cooling module is required per chassis. The cooling
module is located at the top left of the chassis above the Power Entry Modules.
Figure 14: BTI7802 Cooling Module Location
Copyright © 2019, Juniper Networks, Inc.58
BTI7800 Series Hardware Overview and Installation Guide
