Table 6: BTI7800 Chassis Types (continued)
Description
Product Equipment
Code (PEC)Chassis
1-slot chassis
Supports the following service modules:
•
UFM3
•
UFM4
•
UFM6
•
WPS4
•
AMP1
BT8A78CH1BTI7801
NOTE: The collective name, BTI7800, is used to refer to all chassis types
when distinction between chassis types is not needed.
BTI7814 Chassis
The BTI7814 chassis has 14 universal slots that can be individually equipped with
traffic-carrying service modules. The BTI7814 can be installed in 19-inch, 23-inch, and
ETSI 600-mm racks.
Table 7: BTI7814 Chassis Overview
AccessComponent
FrontCMM Slots A and B, to support up to two Chassis
Management Modules
System control
FrontFront panel display
RearChassis Alarm Panel
FrontSlots 1 to 14 from left to right, to support high speed interface
connections for service modules
Service slots
FrontFan modulesCooling
RearBooster fan modules (Only required for chassis operation
with UFM6 modules)
FrontAir intake grill (with access to air filter)
RearFan exhaust
RearPower Entry Modules (AC and DC PEMs)Power management
