Table 60: SFP+ DWDM Tunable 80km Multi-Rate 9.9 to 11.1Gbps (BP3AM6TL) (continued)
UnitsMaximumTypicalMinimumParameter
dB––30Side mode suppression ratio
dB––8.2Extinction ratio
dB27––Optical return loss tolerance
Receiver
nm1600–1260Rx operating wavelength
dBm––3Rx overload
dB-27––Reflectance
Other
LC/BailConnector/Latch type
Typical: 1.7 W
Maximum: 2 W
Power Consumption (40° ambient)
IEEE 802.3, Telcordia GR-253, ITU-T G.709, SFP+ MSACompliance
Table 61: Receiver Transmission Optical Performance Specifications: BP3AM6TL
BER
Receiver Sensitivity
(Min. to Max.)OSNR (dB)Dispersion (ps/nm)Bit Rate (Gbps)
1e
-12
-24 to -7≥3009.95/10.3/10.5
-19 to -7≥25
-22 to -7≥301600
-19 to -7≥26
1e
-4
-26 to -7≥30010.7 (FEC G.709)
-24 to -7≥16.5
-24 to -7≥301600
-24 to -7≥18.5
