Table 55: BTI7800 Series Transceivers (continued)
IntroducedCompatibilityPECBit RateFiber TypeType
Release 4.11x CFP BIC in
UFM3 and UFM4
CFP-100GBASE-CHRT
Installation rules
exist for this
transceiver. See
“Installation Rules for
the 100G Coherent
CFP” on page 177.
100 GbpsSingle-mode100G Coherent CFP-M05
Release 1.1UFM4Integrated on the
Universal Forwarding
Module with
Integrated 100G
Coherent MSA XCVR
(BT8A78UFM4 )
100 GbpsSingle-mode100G Coherent MSA XCVR
Release 4.1UFM6Integrated on the
Universal Forwarding
Module with
Integrated 400G
Coherent MSA XCVR
(BT8A78UFM6-I02)
2 x 200 GbpsSingle-mode400G Coherent MSA XCVR
BTI7800 SFP+ Transceiver Optical Specifications
NOTE: Contact Juniper Networks Support to confirm the power consumption
values for any transceiver before using for planning or implementation
purposes.
Table 56: SFP+ 850nm 200m Dual-Rate 10.3 and 10.5Gbps (BP3AD6SS)
UnitsMaximumTypicalMinimumParameter
Gbps10.52–10.3125Bit Rate
Transmitter
nm860850840TX operating wavelength
dBm-1–-7.3Average operating power
nm0.45––Spectral width (rms)
dB––3Extinction ratio
dB12––Optical return loss tolerance
Receiver
155Copyright © 2019, Juniper Networks, Inc.
Chapter 6: BTI7800 Series Transceiver Specifications
