96-Channel Fixed Mux/Demux Specifications
See Table 51 on page 144 for the FMD96 specifications.
Table 51: FMD96 (BT8A78MD03) Specifications
RangeParameters
Physical
438 mmWidth
88 mmHeight
280 mmDepth
Weight
Environmental
See “Site Requirements” on page 75.Temperature and Humidity
Not applicable, passivePower Consumption
MaximumTypicalMinimumOptical
1566.72 nm1528.77 nmCentral Wavelengths (C-band)
96 channelsNumber of Channels (50-GHz spacing)
6.5 dB4.0 dBInsertion Loss (client in to line out)
6.5 dB4.0 dBInsertion Loss (line in to client out)
22.3 dB19.6 dBMonitor In Port Loss
1
21.2 dB17.9 dBMonitor Out Port Loss
2
23 dBmL1 Composite Input Signal Power
5 dBm/port
3
Client Input Signal Power
1360 nm1310nm1266 nmWavelength (OSC, Line Port)
4
SMF-28 or equivalentFiber Type
LC/UPCConnector
