Table 56: SFP+ 850nm 200m Dual-Rate 10.3 and 10.5Gbps (BP3AD6SS) (continued)
UnitsMaximumTypicalMinimumParameter
nm860–840Receiver operating wavelength
dBm-7.5––Stressed receiver sensitivity (BER =
1e-12)
dBm––0.5Receiver overload
dB3.9––Optical path penalty
dB-12––Reflectance
Other
m300––Reach (50m MMF, 2000 MZHzkm)
LC/BailConnector/Latch type
Typical: 0.8 W
Maximum: 1 W
Power Consumption (40° ambient)
IEEE 802.3, SFP+ MSACompliance
Table 57: SFP+ 1310nm 10km Multi-Rate 9.9 to 11.1Gbps (BP3AM6MS)
UnitsMaximumTypicalMinimumParameter
Gbps11.0957–9.953Bit Rate
Transmitter
nm136013101260Transmitter operating wavelength
dBm0.5–-8.2Average operating power
nm1––Spectral width (-20dB)
dB––30Side mode suppression ratio
dB––3.5Extinction ratio
dB-12––Optical return loss tolerance
Receiver
nm1360–1260Receiver operating wavelength
Copyright © 2019, Juniper Networks, Inc.156
BTI7800 Series Hardware Overview and Installation Guide
