Juniper BTI7800 Series User Manual

Table 57: SFP+ 1310nm 10km Multi-Rate 9.9 to 11.1Gbps (BP3AM6MS) (continued)
UnitsMaximumTypicalMinimumParameter
dBm-10.3––Stressed receiver sensitivity (BER =
1e
-12
)
dBm––0.5Receiver overload
dB3.2––Optical path penalty(@ 6.6 ps/nm)
dB-12––Reflectance
Other
km10––Reach
LC/BailConnector/Latch type
Typical: 0.8 W
Maximum: 1 W
Power Consumption (40° ambient)
IEEE 802.3, Telcordia GR-253, ITU-T G.709, SFP+ MSACompliance
Table 58: SFP+ DWDM Fixed 80km Multi-Rate 9.9 to 11.1Gbps (BP3AM6DL-xx Xx=[01,40])
UnitsMaximumTypicalMinimumParameter
Gbps11.0957–9.953Bit Rate
Transmitter
THz196–192.1Transmitter operating wavelength
dBm3–-1Average operating power
nm0.3––Spectral width (-20dB)
dB––30Side mode suppression ratio
dB––8.2Extinction ratio
dB27––Optical return loss tolerance
Receiver
nm1600–1260Receiver operating wavelength
dBm––3Receiver overload
157Copyright © 2019, Juniper Networks, Inc.
Chapter 6: BTI7800 Series Transceiver Specifications
