Table 58: SFP+ DWDM Fixed 80km Multi-Rate 9.9 to 11.1Gbps (BP3AM6DL-xx Xx=[01,40]) (continued)
UnitsMaximumTypicalMinimumParameter
dB-27––Reflectance
Other
LC/BailConnector/Latch type
Maximum: 1.5 WPower Consumption (40° ambient)
IEEE 802.3, Telcordia GR-253, ITU-T G.709, SFP+ MSACompliance
Table 59: Receiver Transmission Optical Performance Specifications: BP3AM6DL-xx Xx=[01,40]
BER
Receiver Sensitivity
(Min. to Max.)OSNR (dB)Dispersion (ps/nm)Bit Rate (Gbps)
1e
-12
-24 to -7≥30-4009.95/10.3
-18 to -7≥27
-23 to -7≥300
-18 to -7≥25
-22 to -7≥301200
-18 to -7≥27
-22 to -7≥301600
-18 to -7≥28
1e
-12
-20 to -7≥30-40010.5
-18 to -7≥28
-23 to -7≥300
-18 to -7≥26
-22 to -7≥301200
-18 to -7≥28
-18 to -7≥301600
