Table 71: CFP 100GBASE-SR10 100m: BP3AMASS (continued)
UnitsMaximumTypicalMinimumParameter
Gbps-11.1809-Signaling speed per lane (OTU4)
nm860-840TX operating wavelength
dBm2.4--7.6Average launch power per Lane
nm0.65--Spectral width (RMS)
dB--3Extinction ratio
dB12--Optical return loss tolerance
Receiver
nm860-840Receiver operating wavelength
dBm-5.4--Stressed receiver sensitivity per lane
dBm--3.4Rx overload
dB3.5--Optical path penalty
Other
Typical: 10W
Maximum: 12W
Power Consumption (40° ambient)
IEEE 802.3, CFP MSACompliance
Table 72: CFP 100GBASE-LR4 10km: BP3AMDLI
UnitsMaximumTypicalMinimumParameter
Transmitter
Gbps-25.78-Signaling speed per lane (100GbE)
Gbps-27.95-Signaling speed per lane (OTU4)
nm1296.591295.561294.53Lane wavelengths
nm1301.091300.051299.02
nm1305.631304.581303.54
nm1310.191309.141308.09
Copyright © 2019, Juniper Networks, Inc.172
BTI7800 Series Hardware Overview and Installation Guide
