Table 72: CFP 100GBASE-LR4 10km: BP3AMDLI (continued)
UnitsMaximumTypicalMinimumParameter
dBm4.5--4.3Average launch power per Lane
dBm10.5-0Total average launch power
dB--30Side mode suppression ratio (SMSR)
dB--7Extinction ratio (OTU4)
dB20--Optical return loss tolerance
Receiver
dBm-6.8--Stressed Rx sensitivity per lane
dBm5.5--Receiver overload
dB-26--Reflectance
Other
Typical: 20W
Maximum: 24W
Power Consumption (40° ambient)
IEEE 802.3, Telcordia GR-253, ITU-T G.709, CFP MSACompliance
Table 73: 100G Coherent CFP-M05: CFP-100GBASE-CHRT
UnitsMaximumTypicalMininumParameter
Transmitter
Gbps10.3125Signaling speed (100GbE)
Gbps11.1809Signaling speed (OTU4)
THz196.10191.25Transmitter frequency range
GHz1.8-1.8Laser frequency stability
dBm1-15Output power tuning range
dB39Transmitter OSNR (in-band)
dB27Optical return loss tolerance
Receiver
173Copyright © 2019, Juniper Networks, Inc.
Chapter 6: BTI7800 Series Transceiver Specifications
