Page #32 background image
Table 8: BTI7814 Major Common Equipment Components
Release IntroducedPECComponent
Release 1.1BT8A78CAP114-Slot Chassis Alarm Panel
Release 1.1BT8A78FAN314-Slot Chassis Front Cooling Module
Release 4.1BT8A78FAN9BTI7814 Booster Fan
Release 1.1BT8A78PEM3-DC14-Slot Chassis DC Power Entry Module
Release 1.5BT8A78ACM12900W (53.5V) AC Rectifier Module
Release 1.1BT8A78CMM1Chassis Management Module
BTI7814 Chassis Kits
The BTI7814 can be ordered as a kit that includes the bare chassis along with common
equipment modules, tools, and installation hardware:
Table 9: BTI7814 Kits
Component PECQuantityMain Equipment Included
Equipment common to all BTI7814 kits
BT8A78CMM12Chassis Management Module (CMM1)
BT8A78CAP1114-Slot Chassis Alarm Panel (CAP1)
BT8A78FAN3414-Slot Chassis Front Cooling Module
(FAN3)
BT8A78FLR714Line card filler panels (FLR7)
BT8A78TOOLS1Chassis common tool kit (includes chassis
installation kit, BIC extractor tools,
adjustable wrist strap, and other
hardware)
BT8A78671Chassis crimp lug installation kit
14-Slot Chassis, DC-KIT2 (BT8A78CH14-KIT2)
BT8A78CH14114-Slot Chassis, DC, with 4 DC PEMs
(BT8A78PEM3-DC)
14-Slot Chassis, DC-KIT3 (BT8A78CH14-KIT3-DC)
BT8A78CH14114-Slot Chassis, DC, with 4 DC PEMs
(BT8A78PEM3-DC)
Copyright © 2019, Juniper Networks, Inc.32
BTI7800 Series Hardware Overview and Installation Guide
