Table 81: AC Power and Power Cables (continued)
NotesComponent PECComponent
Plug (to power source): NEMA 5-15
Connector (to chassis): IEC 60320 C13
Two cables are required per OPS (one cable for each
OPS AC power unit (BT7A39AE)).
BP1A58GA1.5 meter AC Power Cord with North
American Plug
Two cables are required per OPS (one cable for each
OPS AC power unit (BT7A39AE)).
BP1A58HA1.5 meter AC Power Cord with European
Plug
Two cables are required per OPS (one cable for each
OPS AC power unit (BT7A39AE)).
BP1A58JA1.5 meter AC Power Cord with UK Plug
Two cables are required per OPS (one cable for each
OPS AC power unit (BT7A39AE)).
BP1A58KA1.5 meter AC Power Cord with Australian
Plug
OPS Specifications
All specifications are end of life and over the full operating temperature range.
Table 82: OPS Specifications
SpecificationParameter
Physical and Environmental
436mm (W) x 195mm (D) x 44mm (H)1RU 19" and 23" rack mountable chassis
4 kg (fully populated)Weight
15 W (maximum)Power Consumption
-48 VDC to -60 VDCInput Voltage
-5°C to +55°COperating Temperature Range
-40°C to 70°CStorage Temperature Range
Optical
1500 nm to 1620 nmOperating Wavelength Range 1
1260 nm to 1360 nmOperating Wavelength Range 2
1
4.0 dB (maximum)Insertion Loss
2
(splitter)
0.2 dB (maximum)Polarization Dependent Loss
213Copyright © 2019, Juniper Networks, Inc.
Chapter 9: Optical Protection Switch (OPS)
