NOTE: The BIC can also be placed in hot-swap mode if the BIC is
administratively disabled, or if the containing UFM is administratively
disabled.
5. Loosen the BIC faceplate thumbscrew, located at the top of the BIC. Use a screwdriver
if necessary.
6. When the H/S LED is solid blue, attach the extractor tool to the hole in the bottom
latch and pull simultaneously on the top handle and on the extractor tool.
Gently slide the module all the way out from the UFM.
7. Place the module into an antistatic bag.
8. Attach a BIC filler panel to cover the empty BIC slot.
You have successfully completed this procedure.
Replacing a BIC
Use this procedure to replace a BIC. If you want to replace both BICs in a UFM, you must
replace one BIC at a time.
1. Follow the procedure in “Removing a BIC” on page 126 to remove a BIC.
Remove only one BIC from the UFM.
2. Follow the procedure in “Installing a BIC” on page 125 to install the replacement BIC.
Repeat this procedure if you want to replace the other BIC.
NOTE: If you accidentally remove both BICs from the UFM, perform a warm
reload of the UFM after you install the replacement BICs (system reload warm
ufm ).
Installing or Removing a BIC Filler Panel
Use this procedure to install or remove a BIC filler panel.
Filler panels should always be used to fill an open BIC slot to maintain system temperature
and prevent debris from entering the system.
Copyright © 2019, Juniper Networks, Inc.128
BTI7800 Series Hardware Overview and Installation Guide
