BTI7800 Series Component Power Consumption
NOTE: Before using for planning or implementation purposes, contact Juniper
Networks Support to confirm the power consumption values.
Table 22: BTI7800 Series Component Power Consumption (at 40°C)
Maximum (W)Typical (W)PECModule
Service Modules
3532BT8A78UFM3Universal Forwarding Module (UFM3)
154140BT8A78UFM4Universal Forwarding Module with Integrated
100G Coherent MSA XCVR (UFM4)
–Equipped with 10 QSFP+
4x10GBASE LR or
QSFP+ 4x10G
Ethernet/OTN LR: 305
Equipped with 4 QSFP28
100GE LR4: 295
BT8A78UFM6-I02Universal Forwarding Module with Integrated
400G Coherent MSA XCVR (UFM6)
7568BT8A78AMP196-Channel Amplifier (AMP1 )
00BT8A78MD0396-Channel Fixed Mux/Demux (FMD96)
2422BT8A78WPS4Wavelength Protection Switch (WPS4)
BTI Interface Cards
4338BT8A78SFP12G12x SFP+ BTI Interface Card (12x SFP+ BIC
)
3832BT8A78CFP1G1x CFP BTI Interface Card (1x CFP BIC )
Common Equipment
7770BT8A78CMM1Chassis Management Module (CMM)
7770BT8A78FAN314-Slot Chassis Front Cooling Module
(FAN3)
165150BT8A78FAN22-Slot Chassis Cooling Module (FAN2)
7265BT8A78FAN51-Slot Chassis Front Cooling Module (FAN5)
125–BT8A78FAN9BTI7814 Booster Fan (FAN9)
53Copyright © 2019, Juniper Networks, Inc.
Chapter 2: BTI7800 Series Chassis
