BIC LEDs
Table 46: BIC LEDs
DescriptionColorLEDs
The module is operating normally.GreenActive
The module has failed.RedFail
ON: The module is in a quiescent state, and can be removed from the slot after a
minimum of 5 seconds in this state.
BLINKING: The module is being placed into a quiescent state. It cannot be removed
from the slot.
OFF: The module is operating normally. It cannot be removed from the slot.
BlueH/S (Hot Swap)
For BIC port LEDs, see “Port LEDs” on page 152.
96-Channel Amplifier (AMP1)
The 96-Channel Amplifier module integrates two erbium-doped optical amplifiers to
provide bi-directional amplification of DWDM optical signals in a point-to-point
configuration. The amplifier is optimized for 10-Gbps, 25-Gbps, and 100-Gbps signals. It
includes an embedded optical supervisory channel (OSC) used for span loss control.
Table 47: AMP1 Ports
DescriptionPort
Connects the amplifier to an external monitor.Monitor
Connects the amplifier to a Dispersion Compensation Module (DCM).DCM
Connects the amplifier to a line span.Line
Connects the amplifier to a client.C1
