Table 31: Chassis Installation Kit (BT8A7865) (continued)
FunctionQuantityMain Components
BTI7814 ground lugs to chassis.2Screw M6 X 12 mm, Hex head steel
BTI7802 ground lugs to chassis.2Screw, M4 X 6 mm, Pan head, Phillips, with Ext lock
washer, SS
BTI7802 chassis ground lugs.2Lug, 10-12AWG #12 Stud insulated
BTI7802 chassis ground lugs.2Lug, 10-12AWG #10 Stud insulated
Installation hardware plastic shipping bag.1Packing bag for installation kit
The BTI7814 Chassis Crimp Lug Installation Kit (BT8A7867) is shipped with every BTI7814
chassis:
Table 32: BTI7814 Chassis Crimp Lug Installation Kit (BT8A7867)
FunctionQuantityMain Components
8 power cable lugs plus 2 chassis ground lugs, same
part.
10Dual stud crimp lug #2 AWG Wire, 5/8" Stud pitch, 1/4"
Stud diameter
Installation hardware plastic shipping bag.1Packing bag for installation kit
The following kits and cables are optional and must be ordered separately:
Table 33: Miscellaneous Kits and Accessories
DescriptionPECName
For use when rack-mounting the BTI7814
chassis.
BT8A78SSB1BTI7814 Chassis Shelf Installation
Support Bracket Kit
Replacement air filter elements for the
BTI7814.
BT8A78AFR3BTI7814 Air Filter Elements (10-pack)
Air deflectors for the BTI7802 to
accommodate front to rear airflow in a
23-inch rack.
BT8A78REXBTI7802 Chassis Rear Exhaust Adapter
AC PEM cable for BTI7802 chassis, 1.5m.North America: BP1A58GA
Europe: BP1A58HA
United Kingdom: BP1A58JA
Australia: BP1A58KA
BTI7802 AC PEM Cable
Replacement air filter elements for the
BTI7802.
BT8A78AFR2BTI7802 Air Filter Elements (10-pack)
77Copyright © 2019, Juniper Networks, Inc.
Chapter 4: Installing the BTI7800 Series Chassis
