Removing an FMD96
Use this procedure to remove the FMD96 from a rack.
Tools Required
•
Number 2 Phillips screwdriver (for ground screw)
•
Number 2 Robertson screwdriver or hex wrench (for fasteners that attach the module
to the frame)
•
Antistatic bag
NOTE: Be familiar with the site, safety, and installation guidelines described
in “Module Installation and Removal Guidelines” on page 108.
1. Open the hinged front cover and disconnect the fibers.
CAUTION: When working with the FMD96, follow the safety procedures
associated with equipment containing Laser Safety Hazard Level 1M.
CAUTION: When the ports are optically connected, the module is capable
of passing light from all client and line ports at all times. The client and
line port connections must be limited to Class 1M (21.3 dBm) Laser Safety
Regulations.
2. Disconnect the ground cable. See Figure 51 on page 151
Loosen the ground screw and remove the lug and ground cable. Secure the ground
screw again.
Copyright © 2019, Juniper Networks, Inc.150
BTI7800 Series Hardware Overview and Installation Guide
