Table 38: BTI7800 Series Management and Traffic Modules (continued)
IntroducedPECDescriptionModule
Release 1.1BT8A78AMP1Provides DWDM composite signal
amplification in point-to-point
applications.
NOTE: This module is not supported
on the BTI7801.
96-Channel Amplifier (AMP1)
Release 1.6BT8A78WPS4Provides revertive or non-revertive
wavelength protection switching.
Wavelength Protection Switch (WPS4)
BIC modules
Release 1.1BT8A78SFP12GFor up to 12 SFP+ transceivers.12x SFP+ BTI Interface Card (12x SFP+ BIC)
Release 1.1BT8A78CFP1GFor 1 CFP transceiver.1x CFP BTI Interface Card (1x CFP BIC)
Passive modules
Release 2.0BT8A78MD03Provides local fixed grid access to all
96 wavelengths in the DWDM 50-GHz
channel plan.
96-Channel Fixed Mux/Demux (FMD96)
1
Client ports 1 to 10 support QSFP+ transceivers and client ports 1, 2, 6, 7 support both QSFP+ and QSFP28 transceivers.
Module Installation and Removal Guidelines
All management and traffic modules are hot-swappable. You can install or remove these
modules while the chassis is powered.
WARNING: Use proper caution when working with the equipment. This chapter
might not cover every possible hazardous condition.
NOTE: After installing a module or a BIC into a slot, you must wait a minimum
of 60 seconds before you can remove that module or BIC from the slot. This
allows time for the CMM to recognize that the module or BIC has been
inserted.
NOTE: After removing a module or a BIC from a slot, you must wait a minimum
of 60 seconds before you can install another module or BIC (or that same
module or BIC) into the same slot. This allows time for the CMM to recognize
that the module or BIC has been removed.
Copyright © 2019, Juniper Networks, Inc.108
BTI7800 Series Hardware Overview and Installation Guide
