Table 62: QSFP+ 4x10GBASE LR: QSFPP-4X10GE-LR (740-054050) (continued)
UnitsMaximumTypicalMinimumParameter
SMFFiber type
m10000–2Reach
MTP/APCConnector/Latch type
Maximum: 3.5 WPower consumption
IEEE 802.3Compliance
Table 63: QSFP+ 4x10G Ethernet/OTN LR: QSFPP-4X10GD-LR (740-058730)
UnitsMaximumTypicalMinimumParameter
Gbps–10.3125–10GBASESignaling speed per lane
Gbps–9.95428–OC192/STM64
Gbps–10.709–OTU2
Gbps–11.0957–OTU2e
Gbps–8.5 +/- 100 ppm–8GFC
Gbps–10.51875 +/- 100
ppm
–10GFC
––4–Number of lanes
nm1355–126010GBASELane center wavelength
nm1320–1290OC192/STM64
nm1330–1290OTU2
nm1330–1290OTU2e
nm1360–12608GFC
nm1355–126010GFC
Transmitter
163Copyright © 2019, Juniper Networks, Inc.
Chapter 6: BTI7800 Series Transceiver Specifications
