Number 2 Phillips screwdriver
1. Disconnect all cables from the ESL module.
2. Loosen the thumbscrew holding the module in place. Use a screwdriver if necessary.
3. Remove the faulty ESL module.
Hold the module handle, and slowly slide the ESL module out.
4. Place the ESL module in an antistatic bag or on a grounded antistatic mat.
5. Align the replacement ESL module with the slot guides.
6. Gently push the module until it is connected to the backplane.
7. Tighten the thumbscrew.
8. Reconnect all cables.
You have successfully completed this procedure.
Copyright © 2019, Juniper Networks, Inc.202
BTI7800 Series Hardware Overview and Installation Guide
