Troubleshooting with LEDs on the SRX650 Services Gateway
The LEDs available on the services gateway display the status of various components.
Table 34 on page 126describes the LEDs on the chassis. To view LED information on the
Services and Routing Engine (SRE), see “SRX650 Services Gateway Services and Routing
Engine 6” on page 11.
Table 34: Component LEDs on the Services Gateway Chassis
UsageLocationLED
The POWER LED has the following
indicator colors:
•
Green and steadily on indicates
that all power supply units
(PSUs)are functioning normally.
•
Red and steadily on indicates
failure of one or more PSUs.
•
Amber and steadily on indicates
that the Power button has been
pressed. The services gateway
will shut down gracefully.
•
Off indicates that the device is
not receiving power.
Left side of the front chassis
panel
POWER
The FAN LED has the following
indicator colors:
•
Green and steadily on indicates
fan tray is functioning normally.
•
Red and steadily on indicates fan
tray failure.
•
Off indicates no fan tray.
Left side of the front chassis
panel
FAN
