Juniper SRX650 Hardware Guide

NOTE: The numbers in Figure 2 on page 18 correspond to the numbers in
Table 7 on page 19. The information about numbered slots in
Table 7 on page 19 corresponds to the slot numbers shown in
Figure 3 on page 18.
Table 7 on page 19 provides information about the front panel components of the services
gateway.
Table 7: SRX650 Services Gateway Front Panel Components
DescriptionLocationComponentNumber
Rack-mounting brackets attached
when the services gateway is
mounted on a rack.
The mounting brackets are used to
attach the services gateway to a rack
or cabinet.
Sides of chassisMounting brackets1
The ALARM LED has the following
indicator colors:
•
Red and steadily on indicates a
critical alarm, such as a failure of
a hardware component or
software module, or detection of
a firewall attack.
•
Amber and steadily on indicates a
major alarm, such as low Services
Processing Unit (SPU) memory
(less than 10% remaining), session
full, maximum number of VPN
tunnels reached, HA status
changed, or redundant group
member not found.
•
Off indicates that the device is
starting up.
NOTE: When the systemis up and
running, if the ALARM LED is off, it
indicates that no alarms are
present on the device.
Left side of the
front chassis panel
ALARM LED2
The FAN LED has the following
indicator colors:
•
Green and steadily on indicates
that the fan is functioning
normally.
•
Red and steadily on indicates that
the fan tray has failed.
•
Off indicates that there is no fan
tray.
Left side of the
front chassis panel
FAN LED3
19Copyright © 2018, Juniper Networks, Inc.
Chapter 3: Chassis Description
