Juniper SRX650 Hardware Guide

CHAPTER 11
Cable Specifications and Pinouts
•
Interface Cabling and Wiring Specifications for the SRX650 Services
Gateway on page 59
•
RJ-45 Connector Pinouts for the SRX650 Services Gateway Ethernet Port on page 59
•
RJ-45 Connector Pinouts for the SRX650 Services Gateway Console Port on page 60
Interface Cabling and Wiring Specifications for the SRX650 Services Gateway
The network interfaces supported on the services gateway accept different kinds of
network cables. Table 18 on page 59 lists the specifications for the cables that connect
to ports on the services gateway.
Table 18: Cable and Wire Specifications for Ports and Alarm Interfaces
Device
Receptacle
Maximum
LengthCable/Wire SuppliedCable SpecificationPort
DB-9 male6 ft (1.83 m)One 6-ft (1.83-m) length
with DB-9/DB-9
connectors
RS-232(EIA-232) serial
cable
Console
RJ-45
autosensing
328 ft
(100 m)
One 15-ft (4.57-m)
length with RJ-45/RJ-45
connectors
Category 5 cable or
equivalent suitable for
100Base-T operation
Ethernet
NOTE: The Auxiliary port is not supported on the SRX650 Services Gateway.
RJ-45 Connector Pinouts for the SRX650 Services Gateway Ethernet Port
The port on the front panel labeled ETHERNET is an autosensing 10/100-Mbps Ethernet
RJ-45 receptacle that accepts an Ethernet cable for connecting the services gateway to
a management LAN (or other device that supports out-of-band management).
Table 19 on page 60 describes the RJ-45 connector pinouts for the Ethernet port.
59Copyright © 2018, Juniper Networks, Inc.
