Table 19: RJ-45 Connector Pinouts for Services Gateway Ethernet Port

SignalPin

TX+1

TX-2

RX+3

Termination network4

Termination network5

RX-6

Termination network7

Termination network8

RJ-45 Connector Pinouts for the SRX650 Services Gateway Console Port

The port on the front panel labeled CONSOLE is an autosensing 10/100-Mbps Ethernet

RJ-45 receptacle that accepts an RJ-45 cable for connecting the services gateway to a

management LAN (or other device that supports out-of-band management).

Table 20 on page 60 describes the RJ-45 connector pinouts for the console port.

Table 20: RJ-45 Connector Pinouts for the Services Gateway Console Port

DescriptionSignalPin

Request to SendRTS1

Data Terminal ReadyDTR2

Transmit DataTXD3

Signal GroundGround4

Signal GroundGround5

Receive DataRXD6

Data Set ReadyDSR/DCD7

Clear to SendCTS8
