CHAPTER 3
Chassis Description
•
SRX650 Services Gateway Chassis on page 17
•
SRX650 Services Gateway Front Panel on page 18
•
SRX650 Services Gateway Back Panel on page 24
SRX650 Services Gateway Chassis
The SRX650 Services Gateway chassis is a rigid sheet metal structure that houses all
the other hardware components.
Table 6 on page 17 provides information about the physical specifications for the services
gateway.
Table 6: Physical Specifications for the SRX650 Services Gateway
ValuePhysical Specification
2 rack units (U)Chassis height
17.5 in. (44.4 cm)Chassis width
18.2 in. (46.2 cm)Chassis depth
24.96 lb (11.32 kg)Chassisweight (includes one power supply and one SRE
6 without any GPIMs)
CAUTION: Beforeremovingor installingcomponents of a functioning services
gateway, attach an electrostatic discharge (ESD) strap to an ESD point and
place the other end of the strap around your bare wrist. Failure to use an ESD
strap could result in damage to the device.
The services gateway must be connected to earth ground during normal operation. The
protective earthing terminal on the side of the chassis is provided to connect the services
gateway to ground. Additional grounding is provided to an AC-powered services gateway
when you plug its power supply into a grounded AC power receptacle.
17Copyright © 2018, Juniper Networks, Inc.
