CHAPTER 16
Grounding the SRX650 Services Gateway
•
Required Tools and Parts for Grounding, Powering On, and Powering Off the SRX650
Services Gateway on page 81
•
SRX650 Services Gateway Grounding Specifications on page 81
•
Grounding the SRX650 Services Gateway on page 82
Required Tools and Parts for Grounding, Powering On, and Powering Off the SRX650
Services Gateway
To ground and to provide power to the services gateway, you need Phillips (+)
screwdrivers, numbers 1 and 2.
Related
Documentation
Grounding the SRX650 Services Gateway on page 82•
• Powering On the SRX650 Services Gateway on page 94
• Powering Off the SRX650 Services Gateway on page 95
• Organizing Interface Cables on the SRX650 Services Gateway on page 85
• SRX650 Services Gateway General Safety Guidelines and Warnings on page 165
SRX650 Services Gateway Grounding Specifications
To meet safety and electromagnetic interference (EMI) requirements and to ensure
proper operation, the SRX650 Services Gateway must be adequately grounded before
power is connected. You must provide a grounding lug to connect the services gateway
to earth ground.
WARNING: Beforeservices gateway installation begins, a licensed electrician
must attach a cable lug to the grounding and power cables that you supply.
A cable with an incorrectly attached lug can damage the services gateway
(for example, by causing a short circuit).
To ground the services gateway before connecting power, you connect the grounding
cable to earth ground and then attach the lug on the cable to the chassis grounding point,
using the screw.
81Copyright © 2018, Juniper Networks, Inc.
