Troubleshooting the Power System on the SRX650 Services Gateway
The LEDs on the services gateway enable you todetermine the performance and operation
of the power system. The POWER LED located on the front panel of the services gateway,
as described in Table 36 on page 132, indicates the different status settings with respect
to the power system. The LEDs on the faceplate of each power supply also show power
supply status as described in Table 37 on page 134.
Table 36: POWER LED Description
Possible Cause and Corrective
ActionMeaningLED StateLED Status
Normal indication. No action is
required.
The services gateway
is receiving power,
and all AC and/or DC
power supply units
(PSUs) are working
properly.
OnGreen
If you cannot determine the cause
of the problem or need additional
assistance while troubleshooting
a services gateway, open a support
case using the Case Manager link
at
https://www.juniper.net/support/,
or call 1-888-314-JTAC (within the
UnitedStates) or 1-408-745-9500
(outside the United States).
Indicates failure of
one or more PSUs.
OnRed
Once the services gateway is
running again, continue
troubleshooting.
Power button has
been pressed. The
services gateway will
shut down.
OnAmber
Copyright © 2018, Juniper Networks, Inc.132
SRX650 Services Gateway Hardware Guide
