Juniper SRX650 Hardware Guide

The SRX650 Services Gateway provides PoE ports, which supply electric power over the
same ports that are used to connect network devices. PoE ports allow you to plug in
devices that require both network connectivity and electric power, such as Voice over IP
(VoIP) and IP phones and wireless access points.
The PoE ports for the SRX650 Services Gateway reside on the individual XPIMs. The
SRX650 Services Gateway supports the following XPIMs with PoE:
•
16-Port Gigabit Ethernet XPIM
•
24-Port Gigabit Ethernet XPIM
The active Services and Routing Engine (SRE) manages the overall system PoE power.
You can configure the services gateway to act as power sourcing equipment to supply
the power to the GPIMs connected on the designated PoE ports.
Table 4 on page 9 lists the SRX650 Services Gateway PoE specifications.
Table 4: SRX650 Services Gateway PoE Specifications
Values
Power Management
Schemes
•
IEEE802.3 af
•
IEEE802.3 at
•
Legacy
Supported standards
PoE is supported on the following front panel slots:
•
2
•
4
•
6
•
8
For more information, see “SRX650 Services Gateway Front
Panel” on page 18.
Supported slots
The 645 W AC and 645 W DC power supplies support the
following capacities:
•
255 W @PoE on a single power supply, or with redundancy
using the two power supply option
•
510 W @PoE using the two power supply option operating
as nonredundant
Total PoE power sourcing
capacity
31.2 WPer-port power limit
•
Static: Power allocated for each interface can be configured
•
Class: Power allocation for interfaces is decided based on
the class of powered device connected
Power management modes
For more details about the GPIMs and XPIMs, see the SRX Series Services Gateway for
the Branch Physical Interface Modules Hardware Guide.
9Copyright © 2018, Juniper Networks, Inc.
Chapter 1: Introduction
