Juniper SRX650 Hardware Guide

Table 8: SRX650 Services Gateway Back Panel Components
UsageDescriptionLocationComponentNumber
Power supplies are
hot-swappable and
support single- or
dual-redundantpower
supply versions.
If you need to power
off the services
gateway after it
finishes booting, first
use the CLI to halt the
device.
The power supply
provides power to the
services gateway and its
components. When the
services gateway is
equipped with the two
power supply option,
they work together to
provide redundancyand
load-sharing.
The following power
supplies are available:
•
645 W AC power
supply with PoE
power
•
645 W DC power
supply with PoE
power
Left side of
back panel
2 power supply
slots. Each power
supplycontainsa
power cord
outlet. One
645 W AC power
supply is
provided with the
servicesgateway.
1
The multi-use
processing slot is
rear-pluggable.
The multi-use
processing slot can
contain Application
Co-processor (ACE)
modules, which can
support:
•
Single full-width ACE
processor modules
•
Up to two half-width
ACE processor
modules
NOTE: ACE modules
will be supported in a
future release.
Top center
of the back
panel
Multi-use
processing slot
number SRE 1
2
The SRE 0 slot is
rear-pluggable.
NOTE: The SRE is not
hot-swappable. You
must power off the
services gateway
before removing or
inserting an SRE.
For more detailsabout
the SRE 6 module, see
“SRX650 Services
Gateway Services and
Routing Engine 6” on
page 11.
The SRE 0 slot can
contain one SRE
module.
Bottom
center of
the back
panel
Services and
Routing Engine
(SRE) slot
number SRE 0
3
