Replaceable Parts
Hardware
W30 Cable, Semi-Rigid, Atten B (A10) Port 1 to Transfer Switch (SW2) Port 1 N9038-21314
W31 Cable, Semi-Rigid, Transfer Switch (SW2) Port 2 to RF Presel Input Assy (A21)
J100
N9038-21305
W36 Cable, Semi-Rigid, RF Presel Input Assy (A21) J101 to Transfer Switch (SW2)
Port 3
N9038-21307
W37 Cable, Semi-Rigid, Transfer Switch (SW2) Port 4 to RF Switch/High Band
Preamp (A11) J1
N9038-21315
W38 Cable, Semi-Rigid, RF Switch/High Band Preamp (A11) J2 to Front End Assy
(A13) J2
N9020-20101
W39 Cable, Semi-Rigid, RF Switch/High Band Preamp (A11) J3 to YTF (A12) Input N9020-20123
W40 Cable, Semi-Rigid, YTF (A12) Output to Front End Assy (A13) J9 N9020-20124
W43 Cable, Semi-Rigid, Reference Assy (A16) J701 to Coaxial Switch (SW1) Port 2 N9038-21304
Item Description Part Number
