Keysight N9038A Service Guide

524 Keysight N9038A MXE Service Guide
Replaceable Parts
Hardware
Item Description Part Number
1 Front Frame
---
a
2 A1A1MP9-10 Side Trim Strip W1312-40005
3 A1A1MP11-12 Side Trim Strip, Vinyl 5041-9172
4 A1A1MP2 Main Keyboard Overlay N9038-80001
5 A1MP9 RPG Knob W1312-40017
6 A1MP3 Nameplate Label see Table 17-1
7 A1A1MP3 Overlay, Input 2 N9038-80002
8 A1A1MP7 Blank Cover Plate N9020-00002
9 A1MP7 LCD Glass Filter 1000-1513
10 A1MP8 LCD Lens Gasket W1312-40006
11 A1MP2 Display Keypad E4410-40101
12 Front Frame Ground Spring W1312-00021
13 A1MP1 Main Keypad E4410-40100
14 A1A2MP2 Speaker Foam N9038-40088
15 A1A2MP1 Speaker 9164-0453
16 A1A2 Front Panel Interface Board W1312-63092
17 A1A5 Front Panel Daughter Board N9038-63005
18 A1W1 Flex Circuit, Front Panel Interface to LCD W1312-60010
19 A1A3 Liquid Crystal Display 2090-0911
20 A1MP14 Display Bracket W1312-00115
21 A1MP10-13 Cable Clamp 1400-1439
22 A1MP19 Shield, Front Panel Interface N9020-00051
24 A1W2 Cable Assembly, Wire Harness, Front Panel Interface to
Backlight Power Supply
W1312-60113
25 A1MP17 Shield, Inverter Assembly, Bottom N9020-00011
26 A1A4 Display Backlight Power Supply 0950-4635
27 A1MP15 Shield, Inverter Board W1312-00024
28 A1MP16 Shield, Inverter Assembly, Top N9020-00010
33 A1A6 Input 2 LED Board N9038-63006
34 A1MP20 Bracket, Input 2 LED Board N9038-21202
a. Non-orderable item, see A1A1.
