MDP-621/641/640 Chapter 2
Operation manual Equipment Composition
Chapter 2 Equipment Composition
2.1 Standard equipment list
No. Item name Description Remarks Weight/Length Q’ty
1
Display unit
RGD-600
With cover, mounting
bracket and knurled bolts
3.5kg
1
2 2kW Radome
RB714A
With 10ｍ cable
6kg
3 4kW Radome
RB715A
With 10ｍ cable
10kg
4
Radar Antenna
(Selection)
4kW Open
RB716A
Antenna
(Selection)
3ft：RW701A-03
4ft：RW701A-04
With 10ｍ cable
21kg
(RW701A-03)
22kg
(RW701A-04)
1
5 CW-380-5M To Other Unit
6
LAN cable
CW-385-5M To HUB
5m 1
7
DC Power cable CW-249-2M
For Display
2m 1
8
Hood C23MB41102 1
9 Spare parts Refer to Spare parts lists
2.2
1 set
10 Installation
materials
Refer to Installation
materials lists 2.3
1 set
11
Operation
manual
MDP-600SER.OM.
E
English 1
Remarks: Others shall be selected in 2.4 optional item list
0093161022-06 2-1
