Chapter 2 MDP-621/641/640
Equipment Composition Operation manual
2.2 Spare parts list
(1) MDP-621/641
No. Item name Description Remarks Weight/Length Q’ty
1 Fuse F-7161-15A
/N30C-125V
Fitted in CW-249 6φx30mm 1
2 Fuse ES3-3150
(3.15A)
For antenna motor 5φx20mm 1
(2) MDP-640
No. Item name Description Remarks Weight/Length Q’ty
1 Fuse F-7161-15A
/N30C-125V
Fitted in CW-249 6φx30mm 1
2 Fuse ES3-3150
(3.15A)
For antenna motor
(24VDC)
5φx20mm 1
3 Fuse MF51NN250V
(5A)
For antenna motor
(12VDC)
5φx20mm 2
4 Carbon brush 24Z125209B Attached to antenna
drive motor
1 set
2.3 Installation materials list
(1) MDP-621/641
No. Item name Description Remarks Q’ty
1 Hexagonal bolt B10×25U For antenna unit mounting 4
2 Spring washer SW10U For antenna unit mounting 4
3 Plain washer 2W10U For antenna unit mounting 4
(2) MDP-640
No. Item name Description Remarks Q’ty
1 Hexagonal bplt B12×55U For antenna unit mounting 4
2 Nut N12U For antenna unit mounting 8
3 Spring washer SW12U For antenna unit mounting 4
4 Plain washer 2W12U For antenna unit mounting 8
2.4 Optional items list
No. Item name Description Remarks Weight/Length
2-2 0093161022-06
