MDP-621/641/640 Chapter 2
Operation manual Equipment Composition
1 DGPS sensor KBG-2 (B-TYPE) With 10 m cable with
connector
1.6Kg
2 GPS sensor GPS-20A (B-TYPE) With 10 m cable with
connector
0.74Kg
3 GPS Compass KGC-1 With 15 m Antenna Cable
with 2 pcs. per set / With 5
m Connecting Cable with
6-pin waterproof connector
and one end plain
1.2Kg
4 Sounder unit
CVB-20 Standard sounder
accessory items supplied
2.4Kg
5 7inch Display MDP-621 Standard MDP-621
accessory items supplied
3.5Kg
6 10inch Display MDP-1241 Standard MDP-1241
accessory items supplied
7.0Kg
7 ATA Board MRE-310
8 Gyro/log
interface
GRA-20B With power cable
9 Power rectifier PS-010
With two 5 A fuses
3.5Kg
10 AC Power
cable
VV-2D8 Flying leads both ends (For
power supply)
3m
11 CW-373-5M
6P watertight connector
(LTW) on both ends
5m
12 CW-374-5M
6P watertight connector
(LTW) one end / 6P
connector (Nissin) other end
5m
13 CW-375-5M
6P watertight connector
(LTW) / 6P watertight
connector (Conxall) other
end
5m
14
Connecting
cable
(For Navigator
unit)
CW-376-5M
6P watertight connector
(LTW) one end / Flying
leads other end
5m
15 CW-380-2M 5P watertight connector
(LTW) on both ends
2m
16 CW-380-5M 5P watertight connector
(LTW) on both ends
5m
17
LAN cable
(To other unit)
CW-380-10M 5P watertight connector
(LTW) on both ends
10m
18 CW-385-2M 5P watertight connector
(LTW) one end / RJ45
connector other end
2m
19
LAN cable
(To HUB)
CW-385-5M 5P watertight connector
(LTW) one end / RJ45
connector other end
5m
20 LAN cable
(To HUB)
CW-385-10M 5P watertight connector
(LTW) one end / RJ45
connector other end
10m
21 Connector LTWD-06BFFA-L180 6P watertight connector
(LTW)
0093161022-06 2-3
