Pilot’s Operating Handbook

3A-19

DO NOT USE FOR FLIGHT OPERATIONS

Section 3A

ABNORMAL PROCEDURES

100 SERIES

Abnormal

#2 GPS/NAV Failure

If a failure occurs in the #2 GPS/NAV system (GIA), the other GPS/NAV

system will automatically provide GPS information to both displays. Check

the GPS/NAV circuit breakers to ensure they are both in. If one is open, try

resetting it (push in). If it pops back out, DO NOT reset it.

#2 NAV and #2 COM frequency information will not be displayed on any of

the ight displays. If COM #2 is used, all transmissions will be broadcast on

121.5 MHz. 121.5 MHz is automatically selected when a failure occurs in the

system. COM #1 and NAV #1 may be used as normal.

The following annunciations will be shown on the PFD:

BOTH ON GPS 1 – Both PFD units are receiving GPS data from the No. 1 GIA unit.

AHRS 1 GPS – AHRS 1 not receiving backup GPS information.

TRAFFIC FAIL – Trafc device has failed.

Figure 3A-6 – No. 2 GPS/NAV Computer Failure (No. 1 PFD Shown)

Uncontrolled if printed
