Kodiak 100 Series User Manual

Pilot’s Operating Handbook
6-1
DO NOT USE FOR FLIGHT OPERATIONS
Section 6
WEIGHT AND BALANCE
100 SERIES
Weight & Bal.
SECTION 6
WEIGHT AND BALANCE
Table of Contents
CONTENTS PAGE
GENERAL .............................................................................................................6-3
AIRPLANE WEIGHING PROCEDURES
..............................................................6-4
PREPARATION
..................................................................................................6-4
LEVELING
.........................................................................................................6-4
WEIGHING .........................................................................................................6-4
MEASURING
.....................................................................................................6-5
AIRPLANE WEIGHING FORM
...........................................................................6-6
WEIGHT AND BALANCE RECORD
....................................................................6-7
WEIGHT & BALANCE DETERMINATION FOR FLIGHT
..................................... 6-8
CALCULATING WEIGHT AND BALANCE ........................................................6-8
PASSENGER AND CREW SEAT WEIGHT AND BALANCE
...........................6-10
WEIGHT AND BALANCE LOADING FORM (CONFIGURATION A)
................6-12
WEIGHT AND BALANCE LOADING FORM (CONFIGURATION B)
...............6-14
WEIGHT AND BALANCE EXAMPLE FORM
...................................................6-15
CABIN ZONE LOADING LIMITS ......................................................................6-17
FUEL WEIGHTS AND MOMENTS
................................................................... 6-18
CENTER OF GRAVITY LIMITS
........................................................................6-20
COMPREHENSIVE EQUIPMENT LIST
.............................................................. 6-21
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
