Kodiak 100 Series User Manual

Pilot’s Operating Handbook Supplement
9.5-8
DO NOT USE FOR FLIGHT OPERATIONS
Section 9
CARGO DOORS REMOVED
Cargo Door Remove
100 SERIES
2. Located on the instrument panel:
3. Located on the wind deector:
4. Located adjacent to the handle of the door closing mechanism (if
equipped):
OPERATING LIMITATIONS
WITH DOOR OPEN:
V
max
120 KIAS
V
min
70 KIAS
INTENTIONAL STALLS PROHIBITED.
TAXI, TAKEOFF, LANDING PROHIBITED.
DURING DROPPING:
MAX BANK ANGLE 10°
COORDINATED LEVEL FLIGHT ONLY.
VFR CONDITIONS ONLY.
FLAPS 20°
V
max
80 KIAS
NOT A HAND RAIL.
DO NOT GRASP WIND
DEFLECTOR.
100-750-2609
Uncontrolled if printed

Kodiak 100 Series Specifications

General

Manufacturer	Daher
Engine	Pratt & Whitney Canada PT6A-34
Service Ceiling	25, 000 feet
Seating Capacity	10
Crew	1-2
Range	1, 132 nautical miles
Type	Utility aircraft
Length	34 feet 2 inches
Wingspan	45 feet
Max takeoff weight	7, 255 pounds
Power Output	750 shp
Cabin Width	4 feet 6 inches
